Model |
HT-168 |
|
Product Size |
122*61*37mm |
|
Product Weight |
218g |
|
LOGO Custom |
Yes |
|
Minimum Order Quantity |
Contact with Sales |
|
Model |
HT-168 |
|
Product Size |
122*61*37mm |
|
Product Weight |
218g |
|
LOGO Custom |
Yes |
|
Minimum Order Quantity |
Contact with Sales |
Instant scanning
Digital and analog sub-audio functions
VOX voice-activated launch makes operation more convenient
Chinese/English voice report.
2000mAh large capacity polymer lithium battery pack, smart charger
Beautiful appearance, firm structure and reliable performance. Designed and produced according to American FCC and MIL-STD-810F international certification standards, and tested for high temperature, low temperature, humidity, vibration and impact.
General
Frequency Range:403-470MHz
Working Temperature : -20°C~+60°C
Channel Capacity：16CH
Frequency Stability ：+ 205PPM
perating Voltage：7.2VDC+15%
Dimension(Wthout Antenna)： 122 x 61 x 37mm
Antenna Impedance:50Ω
Weight（W/Battery）： 218g(Li-ion)
Channel Spacking :12.5/25KHz
Battery : 2200mah
TRANSMITTIE(EIA-RS 316B STANDARD)
RF Power Output : 6W/1W
MAX Freq Deviation : <5KHz(1000KHz when 100%)
Modulation Type : F3E
FM Noise : <45dB
Modulation Distortion:<5%(300-3000Hz)
Receiver
(12dB SINAD) Sensitivity(12dB SINAD):0.18μV
Modulation Type:16KOF3E
Selectivity:55dB
Audio Power Output: 500mw when Distortion
Adjacent Channel Selectivity:>70dB
Audio Distorttion:<5%
Noise Respond :>60dB
Operating Bandwidth：+7KHz
FM Noise: 45dB/40dB
