Model |
HT-568 |
|
Product Size |
140*62*45mm |
|
Product Weight |
335g |
|
LOGO Custom |
Yes |
|
Minimum Order Quantity |
Contact with Sales |
|
Model |
HT-568 |
|
Product Size |
140*62*45mm |
|
Product Weight |
335g |
|
LOGO Custom |
Yes |
|
Minimum Order Quantity |
Contact with Sales |
4800mAh large capacity polymer lithium battery pack, smart charger
Number of channels: 16 memory channels
Editable side button function
Flashlight function
Built-in analog sub-audio (CTCSS) and digital sub-audio (DCS) codec function
Chinese/English voice prompts
Emergency alarm function
Computer programming and wireless data copy function between walkie-talkie and walkie-talkie
VOX voice-activated launch function makes operation more convenient
Chinese/English voice report function, easy to operate even in the dark
Beautiful appearance, firm structure and reliable performance. Designed and produced according to American FCC and MIL-STD-810F international certification standards, and tested for high temperature, low temperature, humidity, vibration and impact.
Frequency Range： UHF 400-470MHz
VHF 136-174MHz
Channel:128CH
Voltage:7.2VDC+ 15%
Antenna Impedance:50Ω
Channel Spacing:12.5/25KHz
Working Temperature:-30°C~+60°C
Frequency Stability :+2.5PPM
Dimension(without antenna) ：140x62x45mm
Weight:335g(Li-ion)
Transmitter(EIA 316B STANDARD):
RF Power Output:12W
Modulation Type:F3E
Modulation Distortion:<5%(300-3000Hz)
MAX Freq Deviation :<5KHz(1000KHz When 100%)
FM Noise : < -45dB
Receiver :
Sonsitivity(12dB SINAD):0.18μV
Selectivitu:55dB
Adjacent Channel Selectivity:> 70dB
Noise:Respond: > 60dB
FM Noise:45dB/40dB
Modulation Type:16KOF3E
Audio Power Output:500mW When Distortion
Audio Distortion:<5%
Operarting Bandwidth:+7KHz
